2015 Kia Sedona SX Wagon- 100789b

MSRP

$15

Payments From

$0/mo

More Info

Get in Touch

    Dealer Notes

    TIRES: 8/32 7/328 7/32 7/32  235/65-1

    WINDSHIELD: GOOD

    PDR: FEW

    SET READINESS: YES, P0430

    ODOR: NO

    Vehicle Details

    2015 KIA SEDONA

    KNDMC5C18F6066649

    4 DOOR MINIVAN

    Fuel 37.6%
    Battery 14.0 Volts

    System Scan Summary

    Standard SAE Scan
    C Generic Emission Diagnostics
    Advanced OEM Scan
    Ok Engine Control Module (ECM)
    Ok Transmission Control Module (TCM)
    Ok Antilock Brake System (ABS)
    Ok Supplemental Restraint and Airbags (SRS)
    Ok Body Control Module (BCM)
    Ok Occupancy Detection Sensor (ODS)
    Ok Tire Pressure Monitoring System (TPMS)
    OK Indicates Successful System Scan

    DSR Report Details

    Report Date: 06/04/2026
    Report Time: 03:15 PM EDT
    Report ID: PR-0005652441
    Module ID: B-15424
    Versions: 01.05/03.03
    Rpt Req Time: 03:15 PM EDT
    Report Version: VX-1.1

    Support

    For questions or comments on the VINTEL DSR, please contact your auction, dealership or who provided the report. Arbitration risk is calculated with 2024 NAAA Arbitration Guidelines and may not be indicative of your wholesale auction’s arbitration rules. VinLogX recommends contacting your auction with any questions or concerns.

    Powered By Vintel

    Status

    Exception

    Exception

    Check Engine Light

    Engine Lamp Lit

    On

    Other Dash Lights

    No Bulbs

    Off

    Trouble Codes

    Active DTCS

    Active: 4

    Codes Reset

    Not Reset

    Not Reset

    Emissions

    Pass

    Pass

    Arbitration

    Arbitration Threshold Exceeded

    Risks: 1

    Exception Summary

    No. Explanation
    1. Diagnostics indicate possible weak battery/charging system which may be causing significant electrical faults. Address charging system issues and rescan the vehicle to see if faults clear.
    2. The Check Engine Light or Service Engine Soon is ON.
    3. There are two systems requesting a dashboard warning light to be ON: CATALYST, POWERTRAIN
    4. There are four Current trouble codes reported.
    5. There are two issues identified totaling $1,367 plus labor.
    6. There are three systems affected by trouble codes: BATTERY, CATALYST, POWERTRAIN
    7. There is one issue that may present arbitration risk as defined in the 2024 NAAA guidelines.

    Diagnostic Issue & Deduction Guidance Summary: Total: 2

    Issue Suggested Repair Part(s) Labor Hour(s) Arb Risk
    Catalytic converter passenger side fault. Check aftermarket parts, O2 sensors, replace catalytic converter Passenger side catalytic converter $1117 2.4 X
    Check battery voltage and charging system. For vehicles with 2 batteries, check Battery A first. Battery $250 0.7

    Manual Reset & Emissions Trouble Code Set Analysis

    The vehicle does not indicate a reset by scan tool or by battery disconnect in the last 255 or more warmups.
    The vehicle detected and self-cleared emissions related issues 63 mi ago.
    Emission related issues returned 36 mi after clearing.

    System Readiness Tests (Monitors): Engine type: Spark, Available 8, Failed 0

    Status Description
    Pass Fuel System Test
    Pass Evaporative System Test
    Pass EGR/VVT System Test
    Pass Catalyst Test
    Status Description
    Pass Misfire Test
    Pass Component Test
    Pass Oxygen Sensor Heater Test
    Pass Oxygen Sensor Test

    Diagnostic Trouble Codes (DTC): Current 4, Total 4

    Active
    Intermittent
    Historical
    Source
    DTC
    Description
    X SRS B1102 BATTERY VOLTAGE LOW
    X ODS B1112 BATTERY VOLTAGE TOO LOW
    X X X Generics P0430 CATALYST SYSTEM EFFICIENCY BELOW THRESHOLD BANK 2
    X X Powertrain P0430-E0 CATALYST SYSTEM EFFICIENCY BELOW THRESHOLD BANK 2
    Disclaimer: This report represents the mileage and the diagnostic status codes from the vehicle identified on the report at the time the scan was taken. It is not intended to be a full representation of vehicle condition, safety, value or how fully it complies with applicable regulations. Any further questions about this vehicle should be resolved by a qualified service technician.

    Info

    Industry

    Autos

    Make

    Kia

    Model

    Sedona SX

    Trim

    Wagon

    Year

    2015

    Msrp

    15

    Stock Number

    100789b

    Category

    Car

    Subcategory

    Car

    Condition

    New

    Location

    DTH

    Color

    Gray

    Vin

    KNDMC5C18F6066649

    Odometer

    148102
